CoPick3D 350S

ハードウェア製品一覧へ

Spec


Item
Specification
Processing
384 CUDA Cores
Feature
Color Textured Point Cloud, Color Coded Point Cloud,
Color Texture, Depth Map, Normal Map, Confidence Map
Resolution (points/scan)
Up to 5M
Structured Light Type
White (Standard), RGB Selectable
Baseline (mm)
350
Point-to-point Distance (mm)
Approx. 0.204
Calibration Accuracy (mm)
Up to ±0.1
Temporal Noise (mm)
≤0.1 (typical, with averaging)
Communication
Interface
M12, X-Coded, 8-pole, Female type
Speed
1 Gbps Ethernet
Power
Interface
M12, A-Coded, 4-pole, Male type
Voltage / Current
24VDC / 3A
Weight (kg) - Product / Package
2.7 / 3.8
Size (mm)
(W | D(Connector) | H)
Product
435  | 130 (145) | 70
Package
485 | 195 | 95


※ The product is secured with four 'M6 bolts'.

FOV (Field of View)

Near
  • (WxH) : 271 x 248 mm
  • Working Distance : 450 mm
Focus
  • (WxH) : 499 x 348 mm
  • Working Distance : 650 mm
Far
  • (WxH) : 652 x 562 mm
  • Working Distance : 1,100 mm
